| Camera type |
35mm camera with focal plane shutter and TTL
light metering |
| Film format |
24 x 36mm on 35mm film |
| Lenses |
Intended to be used with short focal length
types of the Carl Zeiss T* ZM-mount lens family in combination
with an external viewfinder.
Other M-mount lenses, including M39 screw mount lenses with an M
– mount adapter can be used |
| Exposure metering |
TTL center-weighted metering at working aperture |
Metering range
at ISO 100 and f/2: |
EV0-EV19 (f/2-4 sec.,f/16-1/2000 sec.) |
| Film speed range |
ISO 25-3200 manually set in 1/3 f-stop
increments |
| Exposure modes |
AE with aperture priority or manual; AE lock
option for a single exposure or for a sequence of exposures;
exposure compensation +/-2 f-stops in 1/3 stops set at shutter
speed dial |
| LED Display |
Combination of 3 LED indicates shutter speed
setting situation |
| Shutter and shutter speed |
Vertical-travel metal focal-plane shutter with
electronically controlled speeds accurate
to 1/12 f-stop |
| Range in Automatic mode |
8 sec. to 1/2000 sec. |
| Range in Manual mode |
1 sec. to 1/2000 sec. in 1-stop increments; B. |
| Flash synch |
Synchronization at 1/125 sec.
and longer shutter speeds |
| Film transport |
Rapid-wind manual advance lever, with ratcheted
partial advance |
| Camera body |
One-piece aluminum base structure, external
magnesium covers, tripod thread 1/4 inch in base, two accessory
shoes for external viewfinder and flash |
| Batteries |
One CR 1/3 Lithium or
two 1.5 V cells type LR44 or SR44 |
| Dimensions |
138mm W x 72.5mm H x 32mm D
(5.4” W x 2.9” H x 1.3” D). |
| Weight |
395g (13.9 oz.) |
